| 纳米板技术性能指标： | ||||
| 纳米隔热板技术性能指标 Technical data | 检验标准 Acceptance standard | |||
| 产品代码 Grade | JSGW-1000 | JSGW-1200 | ||
| 分级温度 Classification temperuture | 1000 ℃ | 1200℃ | ||
| 密度（±10%） Nominal density | 350 kg/m³ | 320kg/m³ | GB/T17911-2006 | |
| 抗压强度 Compressive strength | 0.4 MPa | 0.5MPa | GB/T13480-1992 | |
| 比热容（400℃）Specific heat capacity | 0.8 kJ/kg.k | 0.8kJ/kg.k | YB/T4130-2005 | |
| 线收缩率(800℃）Shrinkage | 1% | 1% | GB/T17U911-2006 | |
| 导热系数(w/m.k) Thermal conductivity | 400℃ | 0.024 | 0.015 | YB/T4130-2005 |
| 800℃ | 0.04 | 0.019 | ||
| 1000℃ | 0.043 | 0.025 | ||
| 尺码 Sizes | ||||
| 板厚范围 Thickness range | ||||
| 生产公差 Production Tolerance | ||||
| 长和宽 Length and width | ||||
| 厚度 Thickness | 10-40mm | |||
